Model

WIS5016

Video / Audio input

Video Compression

H.264 High Profile

Coaxial Video Input

16-ch 1080P

Video Input Interface

BNC (1.0 Vp-p,75 Ω)

Video Frame

PAL：1/15--25fps/s，NTSC：1/16--30fps/s

Network Video Input

16-ch 1080p IPC (4-ch 1080p Playback)

Composited Video Input

8-ch 1080P AHD + 8-ch 1080p IPC (4-ch 1080p Playback)

Audio Compression

G.711A

Audio Input

4-ch, RCA

Video / Audio Output

HDMI Output

1-ch，HDMI

VGA Output

1-ch，VGA

Audio Output

1-ch，RCA

Record / Playback

Record Mode

Manual, Continuous, Video Alarm Trigger(Motion detection, Video Loss and Blank)

Playback Search Mode

Date/Time, Event(alarm,motion detection) Search, Smart search, Log link

Synchronous Playback

8-CH 1080P

Backup Mode

Flash Drive, USB HDD, Network, CD-RW or DVD-RW

Hard Drive

SATA

2* SATA Interface

Capacity

Up to 4TB for each disk

External Interface

Network Interface

1* RJ45 10M/100M Mbps Self-Adaptive Ethernet Interface

Serial Interface

1* RS-485

USB Interface

3* USB 2.0

Alarm Input

No

Alarm Output

No

General

Power Supply

DC 12V

Consumption (without HDD)

≤15W

Working Temperature

0℃-＋55℃

Working Humidity

10%－90% RH

Dimension (W*D*H)

325 x 245 x 50mm

Weight (without HDD0

≤1.4Kg
