Specification
|
T2
|
|
Optoelectronic
|
|
|
Lens
|
Fisheye lens, f=1.29mm, F=2.2
|
|
Field of Vision
|
Horizontal 185°/Vertical 185°
|
|
Iris
|
Fixed
|
|
Sensor
|
1/3"
Progressive Scan CMOS
|
|
Sensibility
|
0.2Lux@F2.2(Color)/0.02Lux@F2.2(B/W)
|
|
Day/Night
|
Auto switch IR
cut
|
|
IR
Illumination
|
1W@850nm
|
|
|
|
|
Image Flip
|
Horizontal/Vertical
|
|
Adjustment
|
Brightness,
Saturation, Sharpness, Contrast, Tone
|
|
Max.
Resolution
|
1.3 Megapixels（1280×1024）
|
|
Video Coding
|
Dual Stream
H.264
|
|
Bit Rate
|
100Kbps~5120Kbps
|
|
Max. Frame
Rate
|
25fps
|
|
Audio
|
|
|
Microphone
|
Internal
|
|
Audio Coding
|
G.711
|
|
Pickup Distance
|
6 Meters
|
|
Panoramic
Function
|
Enabled by software
|
|
Panoramic
Display
|
360° panoramic
expansion-view,180° 2 split-view, 90° 4 split-view
Longitude and
latitude correcting view(wall mounted)
|
|
DPTZ
|
Digital PTZ，Pan/Tilt/Zoom
|
|
Intelligent
Function
|
|
|
Motion
Detection
|
20×15 Regional
detecting, Sensibility 1~6 adjustable
|
|
Alarm Function
|
|
|
Alarm Trigger
|
Motion
Detection/Video Tampering/Abnormal procedure/Alarm Input
|
|
Alarm Action
|
Alarm
Record/Image Snap， Alarm
Video/Image Upload（FTP/Email）
|
|
Network
|
|
|
Protocol
|
TCP/IP，HTTP，DHCP，DNS，RTP/RTSP，FTP，PPPOE，SMTP，NTP
|
|
Compatibility
|
ONVIF2.0
|
|
Interface
|
|
|
Communication
Port
|
1 RJ45
10M/100M Ethernet
|
|
Power
Interface
|
ø5.5-2.1mm
round DC socket
|
|
Local Storage
|
Up to 128G SD
Card
|
|
General
|
|
|
Power Supply
|
DC12V±10%，1A
|
|
Power
Consumption
|
<6W
|
|
Working
condition
|
-15℃~+50℃@Humidity 10%~ 95%
|
|
Storage Condition
|
-40℃~+75℃@Humidity 10%~
95%
|
|
EMC
|
CE，FCC
|
|
Housing
|
PC
cream-colored
|
|
Protection
Grade
|
IP50
|
|
Product Size
|
Φ100*36.6mm
|
|
Weight（kg）
|
N.W.：0.1 / G.W.：0.2
|
