System solutions

GM8136S+SC2135

Lens

1/2.7" Fisheye lens, f=2.5mm,F=1.9

Field of view

Level 184°/ Vertical 79°

aperture

Fixed

Imaging device

1/2.8"line-by-line scan CMOS

Sensitivity

0.2Lux@F2.0(colors)/0.02Lux@F2.0(Black and white)

Day and night switching

Infrared dual filter switch


Maximum resolution

1920*1080

Panoramic imaging of effective pixels

1750, 000

Video encode

H.264 Dual stream

Frame rate

25  Frame / Sec

Audio

Audio code

AAC/G.711，Support two-way voice intercom

The internet

Frequency Range

2.4GHz～2.4835GHz

WIFI

IEEE802.11b/g/n

User interface

Power supply interface

MicroUSB

Local storage

1 pcs TF（MicroSD）Storage interface，Maximum support128G

Indicator light

1 pcs  LED（2colors）

speaker

8Ω1W

Reset

A key for reset

Infrared lighting

2 pcs0.7W@850nm In series connect

General parameters

Power

DC5V，<1A

Power consumption

<5W

Working condition conditions

-10℃~+50℃@ humidity 10%~95% No condensation

Storage conditions

-40℃~+75℃@ humidity 10%~95% No condensation

APP

1.Support IOS / Android;

2.Supports the use handset real-time examination video frequency and playback video frequency;

3.Support the use of mobile phones for local video and screenshots;

4.Support alarm information screenshots push;

5.support two-way voice intercom;
