product parameters

System

DSP

Embedded micro HI3507

Operation System

LINUX System

Vedio

Sensor

CMOS 0.3MP

Image Coding

H.264

Video Standard

PAL & NTFS

Resolution

VGA:640*480

Playback

VGA@ 25 fps or 30 fps

Motion Detection

Support

Minimum Illumination

0.1LUX/F1.2

Vedio call

Support

Snapshot

Support

Vedio output

BT656/TFT LCD

Audio

Encoding Standard

G.711A

Audio input

Built-in microphone or earphone

Audio output

Built-in speaker or earphone

Record Management

Recording

Manual record、MD record、Timing record、Alarm record

Storage

USB、TF card

Alarm

Alarm input

Wireless sensor alarm

Alarming

Speaker alarm、Alarm record、Snapshot、Send Email

Others

Network

1*RJ45, 10/100/1000M ethernet

USB

1*USB 2.0

TF

1*TF card

Wifi

Support，802.11 b/g/n

Earphone

1*3.5mm earphone interface

Power Supply

DC 12V 2A

PTZ

inner horizontal and vertical machine

Power

2W

Temperature

0℃－＋55℃

Humidity

10%－90%

Size

110*120*240MM

Weight

500g

Installation

Rack Installation
